ISO9001 Auxiliary Machine 3kW Metal Waste Crusher Machine 300kg/H

Name: ISO9001 Auxiliary Machine 3kW Metal Waste Crusher Machine 300kgH
Brand: Sanqing
Price: 1 USD

China ISO9001 Auxiliary Machine 3kW Metal Waste Crusher Machine 300kg/H wholesale

Brand Name : Sanqing

Certification : CE ISO9001

Place of Origin : Hebei, China

MOQ : 1 set

Supply Ability : 30 sets/month

Delivery Time : 45 days

Packaging Details : Angle frame with outside wooden case

Product Name : Industrial Double Two Shaft Blades Plastic Metal Tire Pipe Waste Scrap Material Shredder Crusher Machine

Production Capacity : 150-300kg/h

Voltage : 380V 50Hz 3PH or customized

Power : 3kW

Weight : 500kg

Warranty : 1 year

Contact Now

Product name:

Industrial Double Two Shaft Blades Plastic Metal Tire Pipe Waste Scrap Material Shredder Crusher Machine

Product Paramenters

Zillion Powerful Plastic Crusher Specifications
Model	Power	Crusher Capactiy	Size	Weight
ZL-PC180	2.2kw/3HP	80-120kg/h	5004201000mm	150kg
ZL-PC250	4kw/5HP	130-250kg/h	7506201040mm	280kg
ZL-PC300	5.5kw/7.5HP	220-300kg/h	8506801220mm	350kg
ZL-PC400	7.5kw/10HP	400-500kg/h	8808401300mm	450kg
ZL-PC500	11kw/15HP	400-500kg/h	110010001520mm	650kg
ZL-PC600	15kw/20HP	600-800kg/h	1200*11201630mm	751kg
ZL-PC700	22kw/30hp	700-900kg/h	130012401860mm	1050 kg
ZL-PC800	30kw/40HP	800-1000kg/h	160013802030mm	1450kg
ZL-PC1000	38kw/50HP	1000-15000kg/h	190015802200mm	2000kg
*Specification may be change without notice.

Products Description

Introduction of waste wood pallet double shaft shredder

Double shaft shredder also called cutting shredder through cutting and extrusion to reduce the material size,widely used in the waste plastic,scrape rubber,scrap metal,wood,garbage and other large volume of waste.our company provide shredding machine equipment with mature technology,advanced design and reliable quality to crush and reduce volume before waste recycling.This double shredding machine by the PLC automatic control,with which has start, stop,reverse andautomatic reverse in overload condition

Main Features of Scrap Metal/Root Crusher Waste Car Shredder Machine For Sale

1.Low noise, less dust with high capacity.
2.Special thick plate precision machining combination frame, large angle hexagonal column of the strong rotation axis, large diameter solid into the hopper, so you can safely put into large raw materials.
3. In the thickness, shape, arrangement and other aspects of the design and processing of a unique rotary knife, shear strong,sharp blade, can be highly efficient broken.
4. Unique multiple combination sealing structure effectively blocks the contact of broken material and grease.
5. The moving blade material is made of special alloy tool steel forging blanks, precision machining, multiple heat treatments and low temperature freezing heat treatment technology.

Model	FT2S-300*180	FT2S-400*180	FT2S-500*180	FTS-300*180	FTS-400*180	FTS-500*180
Motor	3KW-4,2set	4KW-4,2set	7.5KW-4,2set	3KW-4,1set	4KW-4,1set	7.5KW-4,1set
Reducer	JKA77,2set	JKA87,2set	JKA97,2set	JKA77,1set	JKA87,1set	JKA97,1set
Control panle	PLC System protection	PLC System protection	PLC System protection	PLC System protection	PLC System protection	PLC System protection
Input Speed(rpm)	₁₆	₁₇	₁₅	₁₅	₁₇	₁₅
Input Torque(Nm)	₃₁₀₇	₃₉₅₂	₈₂₅₅	₁₆₉₆	₂₁₇₆	₄₅₇₄
Input shaft diameter(mm)	_Φ60	_Φ60	_Φ70	_Φ60	_Φ60	_Φ70
Tool size( mm)	_Φ180*12	_Φ180*15	_Φ200*20	_Φ180*12	_Φ180*15	_Φ200*20
Number of tools( pcs)	₂₅	₂₆	₂₅	₂₅	₂₆	₂₅
Feed port size( mm)	_500500300	_500600300	_600700400	_500500300	_500600300	_600700400
Dimension (mm)	_{12005001300}	_{14005001450}	_{16006001550}	_8505001300	_{11206001480}	_{12006001550}

Fante Small waste shredder is very popular for house hold, the size of breaking chamber is only 400*400/300*200/200*200mm, this model suitable for home,small scale recycling centers.The capacity for crushing is around 350kg/hr. It features with small size,soft price,quick lead time, perfect performance & multi-application. With this mini shredder you can save lots of space and cost of transportation, by selling crushed materials will bring you more profit.

Technologies:

* High number of rotations (15-35 rpm)
* Single shaft with parallel axis engine reducer
* Configurable automatic gear reversal
* Bearings outside of the cutting chamber
* Automatic greasing managed by PLC
* Use of high quality steels
* Configurable blades for thickness and number of teeth
